DISPLAY VISIONS EA DIP205 Text Displays

DISPLAY VISIONS EA DIP205 Text Displays have a high-contrast LCD supertwist display and various interfaces for seamless connectivity. The DISPLAY VISIONS EA DIP205 features a controller RW1073-0B compatible with SSD1803. The displays offer an interface for 4- and 8-bit data buses and a serial SPI interface (SID, SOD, SCLK) for added versatility. With a power supply of +3.3V/1.5mA (with or without B/l) or +5V (with only 2 component changes).

Features

  • High-contrast LCD supertwist display
  • Interface for 4- and 8-bit data BUS
  • Serial SPI interface (SID, SOD, SCLK)
  • Power supply +3.3V/1.5mA (with or without B/l)
  • Alternatively +5V (need to change two components)
  • LED backlight Y/G max. 150mA@+25°C
  • LED backlight blue-white and black-white max. 45mA@+25°C
  • Operating temperature range -20°C to+70°C
  • Built-in temperature compensation
  • Modules with the same size and same pinout
    • Dot-matrix 1x8, 2x16
    • Graphic 122x32
  • No screws are required; solder onto PCB only
  • Detachable via 9-pin socket EA B200-9 (2 pcs required)

Dimensions

DISPLAY VISIONS EA DIP205 Text Displays
