M24308/24-9F

Name: ITT Cannon M24308/24-9F
Brand: ITT Cannon
SKU: 965-M24308249F
Price: 30.67 GBP
Availability: InStock

Images are for reference only
See Product Specifications

Mouser No:

965-M24308249F

Mfr. No:

M24308/24-9F

Mfr.:

ITT Cannon

Description:

D-Sub Mil Spec Connectors Pin, Std Density Cadmium,3 ,25

Datasheet:

M24308/24-9F Datasheet (PDF)

ECAD Model:

Download the free Library Loader to convert this file for your ECAD Tool. Learn more about the ECAD Model.

More Information

Learn more about ITT Cannon M24308/24-9F

In Stock: 26

Stock:: 26 Can Dispatch Immediately

An unexpected error occurred. Please try again later.
Factory Lead Time:: 16 Weeks Estimated factory production time for quantities greater than shown.

Enter Quantity:

Minimum: 1 Multiples: 1

Unit Price:

£-.--

Ext. Price:

£-.--

Est. Tariff:

Pricing (GBP)

Qty.	Unit Price	Ext. Price
	£30.67	£30.67
	£28.66	£286.60
	£26.35	£658.75
	£20.43	£1,021.50
	£19.44	£1,944.00

.hidden-for-nojs { display: none; } .pull-right-nojs { justify-content: flex-end; }

Product Attribute	Attribute Value	Select Attribute
Manufacturer:	ITT Cannon
Product Category:	D-Sub Mil Spec Connectors
Product:	Connectors
Termination Style:	Crimp
Contact Plating:	Gold
Mounting Style:	Free Hanging
Series:	KPT
Brand:	ITT Cannon
Contact Material:	Copper Alloy
Country of Assembly:	Not Available
Country of Diffusion:	Not Available
Country of Origin:	MX
Current Rating:	7.5 A
Product Type:	D-Sub MIL Spec Connectors
Shell Material:	Steel
Shell Plating:	Cadmium
Factory Pack Quantity:	1
Subcategory:	MIL-Spec / MIL-Type
Part # Aliases:	130774-0114
Unit Weight:	2.268 g

Products found:

To show similar products, select at least one checkbox

Select at least one checkbox above to show similar products in this category.

Attributes selected: 0

Filter Document:

Datasheet

M24308/24-9F Datasheet (PDF)

This functionality requires JavaScript to be enabled.

CAHTS:: 8536690020
USHTS:: 8536694040
JPHTS:: 853669000
KRHTS:: 8536691000
TARIC:: 8536693000
BRHTS:: 85366990
ECCN:: EAR99

M24308 D-Subminiature Connectors

ITT Cannon M24308 D-Subminiature Connectors are designed to offer ruggedized interconnect solutions that transfer data, signal, and power in a compact design. These connectors feature a resourceful interface for mission-critical platforms and programs. ITT Cannon M24308 D-sub Connectors can be configured for in-line termination using crimp contacts and solder cup or for straight and PCB-mounted applications. These connectors feature 1000V_AC at sea level DWV rating, standard and high-density configurations, solder and crimp cable versions, and fixed or float mount options. Typical applications include long-range subsonic cruise missiles, advanced shipboard communications, technology-driven UAVs, and next-generation commercial aircraft systems.
